Casio G-Shock Mudmaster GWG-1000DC-1A5DR

Casio G-Shock Mudmaster GWG-1000DC-1A5DR

Features

From MASTER OF G, the timepiece series that supports adventurers who face the rigors of the natural environment, comes new color model for the MUDMASTER (GWG-1000) series watches designed for on-land adventuring.
This new model is designed and engineered for use in deserts, which is some of the harshest land-based environments in the world.
The bodies of this model is done in basic G-SHOCK black, while bezel markings and hour markers are gold and beige, creating an adventurous, masculine design.
From functions to designs, everything about this new MASTER OF G model maintains and enhances a proud tradition of timepieces for men who face extreme conditions head on.

• MULTIBAND 6: Automatic adjustment of time settings based on reception of one of six time calibration signals around the globe: Japan (2), China, United States, England, Germany
• Tough Solar
• Smart Access
• Auto hand position correction
• Mud resist structure (Dust-resistant, mud-resistant structure)
• Vibration resistant structure
• Barometric pressure/altitude, bearing, temperature readings
• Double LED light illuminates the face and digital display for high readability
• Screw-in crown

Mud resist structure (Buttons)
All buttons are dust resistant and mud resistant, without any sacrifice of operability. Gaskets between the button pipes and buttons guard against the invasion of mud.

Mud resist structure (Crown)
Gasket: A gasket between the crown and case maintains outstanding mud resistance.
Warning indicator: A red warning indicator provides a visual reference of the crown’s lock/release state.
Vibration resistant structure
α GEL® at the bottom and on the sides of the module absorbs vibration. α GEL® protects the watch against operation problems, damage, and other trouble due to vibration. Washers where the band joins the case also prevent screws from coming loose due to vibration.

Specifications

• Case / bezel material: Resin / Stainless steel
• Resin Band
• Mud Resistant
• Neobrite
• Screw Lock Crown
• Vibration resistant
• Shock Resistant
• Sapphire Glass with non-reflective coating
• 200-meter water resistance
• Double LED light
  • LED light for the face (Full auto LED light, selectable illumination duration, afterglow)
  • LED backlight for the digital display (Full auto LED light, selectable illumination duration, afterglow)
• Solar powered
• Time calibration signal reception
  • Auto receive up to six* times a day (remaining auto receives canceled as soon as one is successful)
  • *5 times a day for the Chinese calibration signal
  • Manual receive
  • The latest signal reception results
• Time Calibration Signals
  • Station name: DCF77 (Mainflingen, Germany)
  • Frequency: 77.5 kHz
  • Station name: MSF (Anthorn, England)
  • Frequency: 60.0 kHz
  • Station name: WWVB (Fort Collins, United States)
  • Frequency: 60.0 kHz
  • Station name: JJY (Fukushima, Fukuoka/Saga, Japan)
  • Frequency: 40.0 kHz (Fukushima) / 60.0 kHz (Fukuoka/ Saga)
  • Station name: BPC (Shangqiu City, Henan Province, China)
  • Frequency: 68.5 kHz
• The auto hand home position correction
• Digital compass
  • Measures and displays direction as one of 16 points
  • Measuring range: 0 to 359°
  • Measuring unit: 1°
  • 60 seconds continuous measurement
  • Hand indication of north
  • Bidirectional calibration
  • Magnetic declination correction
• Altimeter
  • Measuring range: –700 to 10,000 m ( –2,300 to 32,800 ft.)
  • Measuring unit: 1 m (5 ft.)
  • Hand indication of altitude differential
  • Manual memory measurements (up to 30 records, each including altitude, date, time)
  • Auto log data (High/low altitudes, cumulative ascent and descent)
  • Others: Relative altitude readings (±100m /±1000m),
  • Selectable measurement interval: 5 seconds or 2 minutes
  • *1 second for first 3 minutes only
  • *Changeover between meters (m) and feet (ft)
• Barometer
  • Display range: 260 to 1,100 hPa (7.65 to 32.45 inHg)
  • Display unit: 1 hPa (0.05 inHg)
  • Hand indication of pressure differential
  • Atmospheric pressure tendency graph
  • Barometric pressure tendency information alarm (beep and arrow indicates significant changes in pressure)
  • *Changeover between hPa and inHg
• Thermometer
  • Display range: –10 to 60°C (14 to 140°F)
  • Display unit: 0.1°C (0.2°F)
  • *Changeover between Celsius (°C) and Fahrenheit (°F)
• World time
  • 29 time zones (29 cities + coordinated universal time), daylight saving on/off, Home city/World time city swapping
• 1/100-second stopwatch
  • Measuring capacity: 23:59’59.99”
  • Measuring modes: Elapsed time, split time, 1st-2nd place times
• Countdown timer
  • Measuring unit: 1 second
  • Countdown range: 60 minutes
  • Countdown start time setting range: 1 second to 60 minutes (1-minute increments)
• 5 daily alarms
• Hourly time signal
• Hand shift feature (manual or auto (during altitude, barometric pressure, and temperature measurement))
• Battery level indicator
• Power Saving (display goes blank and hands stop to save power when the watch is left in the dark)
• Full auto-calendar (to year 2099)
• 12/24-hour format
• Button operation tone on/off
• Regular timekeeping
  • Analog: 3 hands (hour, minute (hand moves every 10 seconds), second)
  • Digital: Hour, minute, second, am/pm, date, day
• Accuracy: ±15 seconds per month (with no signal calibration)
• Approx. battery operating time:
  • 6 months on rechargeable battery (operation period with normal use without exposure to light after charge)
  • 25 months on rechargeable battery (operation period when stored in total darkness with the power save function on after full charge)
• Size of case : 59.5×56.1×18mm
• Total weight : 119g
